1510C Audio Snake Cable
- Audio Snake Cable designed for multi-channel analog audio interconnections.
- 4-pair, 24 AWG construction with tinned copper conductors.
- 7×32 stranding provides a flexible conductor construction.
- Individually shielded pairs for improved protection against interference.
- Features Beldfoil® shielding with 100% coverage.
- Includes an overall Beldfoil® shield and drain wire.
- Polyolefin insulation with numbered/color-coded PVC inner jackets.
- Flexible PVC outer jacket with a rip cord for convenient cable preparation.
- Suitable for connecting microphones, speakers, amplifiers, and mixing consoles.
- Ideal for live events, studio sound, and professional analog audio systems.
- 300 V UL voltage rating.
1512C Audio Snake Cable
Highlights
- Audio Snake Cable designed for multi-channel audio interconnections.
- 8 pairs of 24 AWG tinned copper conductors for reliable signal transmission.
- Individually shielded pairs using Beldfoil® bonded to color-coded and numbered PVC jackets.
- Overall Beldfoil® shield with drain wire provides additional protection against interference.
- Flexible PVC outer jacket for easier handling and installation.
- Suitable for analog audio applications.
- Ideal for connecting microphones, speakers, amplifiers, and mixing consoles.
- Suitable for live events and studio sound applications.
- 100% shield coverage for both inner and outer shields.
- 300 V RMS UL voltage rating.
- Operating temperature: -35°C to +75°C.
- Maximum current: 1.05 A per conductor at 25°C.
- Nominal conductor resistance: 23.3 Ω/1000 ft.
- Nominal capacitance: 31 pF/ft conductor-to-conductor and 58 pF/ft conductor-to-other conductors/shield.
1514C Audio Snake Cable, #24-16pr
- 16-pair Audio Snake Cable designed for multi-channel audio interconnections.
- 24 AWG tinned copper (TC) conductors with 16 pairs.
- Individually shielded pairs using Beldfoil® for effective protection against interference.
- 100% shield coverage on both the inner and outer shields.
- Numbered and color-coded PVC jackets for easy pair identification and installation.
- Flexible PVC outer jacket with an integrated rip cord for easier cable preparation.
- Ideal for microphones, speakers, amplifiers, and mixing consoles.
- Suitable for live events, studio sound, and analog audio applications.
- 50 Ω nominal characteristic impedance.
- 66% nominal velocity of propagation.
- 300 V RMS UL voltage rating.
- Operating temperature: -35°C to +75°C.
1513C 12 PAIR SNAKE CABLE - AUDIO
Highlights
- 12-pair Audio Snake Cable designed for multi-channel audio interconnection.
- Uses 24 AWG (7 × 32) tinned copper conductors for each pair.
- Individually foil-shielded pairs with 100% Beldfoil® coverage.
- Overall Beldfoil® shield provides additional protection against signal interference.
- 24 AWG tinned copper individual drain wire for the pair shields.
- 18 AWG tinned copper overall drain wire for the outer shield.
- Polypropylene (PP) insulation with numbered and color-coded inner jackets for easy identification.
- Inner pair jackets are adhered to the individual shields, allowing easy and simultaneous stripping.
1516C 24 PAIR SNAKE CABLE - AUDIO
Highlights
- 24-pair Audio Snake Cable designed for multi-channel audio interconnection.
- Uses 24 AWG, 7 × 32 tinned copper conductors.
- Individually shielded pairs with Beldfoil® bi-laminate shielding.
- 100% shield coverage for both individual pairs and the overall cable shield.
- Polypropylene (PP) insulation with numbered and color-coded pairs for easy identification.
- Flexible PVC inner and outer jackets with an integrated rip cord for easier stripping.
- Suitable for microphones, speakers, amplifiers, and mixing consoles.
- Ideal for live events, studio sound, and analog audio applications.
- Nominal characteristic impedance: 50 Ω.
- Nominal conductor DCR: 23.3 Ω/1000 ft.
- Nominal capacitance: 31 pF/ft conductor-to-conductor and 58 pF/ft conductor-to-other conductors + shield.
